APS TUBE PNEUMATIC CLEANING AM-1 100

Product Introduction

APS TUBE PNEUMATIC CLEANING AM-1 100 is a heavy-duty pneumatic pipe cleaning system designed for medium-bore industrial pipeline pre-commissioning and maintenance. It delivers high-efficiency cleaning for pipes of various materials, including rubber hoses, aluminum tubes, copper tubes, stainless steel pipes, iron pipes, plastic pipes, rigid pipes and flexible hoses.

Applicable Pipe Inner Diameter: 63mm – 100mm. Larger bore sizes are available upon custom request.

Industry Applications

1. Machinery Manufacturing: Pipeline cleaning for construction machinery and lifting equipment
2. HVAC & Refrigeration: Servicing condensers, heat exchangers and evaporators
3. Aerospace: Assembly, maintenance and cleaning of hydraulic transmission systems
4. Coal Mining: Cleaning, assembly, maintenance and troubleshooting of hydraulic transmission pipelines for hydraulic supports
5. Marine & Shipping: Cleaning, assembly, maintenance and troubleshooting of fuel pipelines and power transmission systems
6. Food Industry: Residue removal for pre-assembly pipes, raw material and finished product transfer lines, multi-bend semi-liquid pipelines and multi-bend valve piping
7. National Defense & Military: Maintenance and troubleshooting of fuel pressure transmission systems, gun barrels and hydraulic systems for warships, fighter jets, rocket launchers, tanks, artillery and engineering vehicles

Working Principle This equipment adopts dry physical cleaning technology powered by compressed air. The launcher fires a specially engineered foam projectile with a calibrated diameter slightly oversized relative to the pipe inner bore. The foam projectile travels at high velocity through the pipeline and creates full friction against the pipe inner wall to strip contaminants. It can navigate complex multi-bend piping layouts, such as 90° elbows, T-joints, annular loops, U-bends and serpentine lines. It effectively removes trapped water, sludge, welding debris, oil residues and other deposits accumulated on pipe inner surfaces.

Key Advantages of APS TUBE PNEUMATIC CLEANING AM-1 100

1. Medium-bore dedicated design: Optimized for 63–100mm pipelines, ideal for large hydraulic tubes, heat exchanger bundles and industrial process piping.
2. Robust pneumatic power output: Stable propulsion performance to handle heavy contaminants in thick-walled metal pipelines.
3. Wide material compatibility: Safe for both rigid and flexible pipes without scratching or damaging pipe substrates.
4. Strong routing adaptability: Reliably passes intricate multi-bend piping where conventional water flushing cannot achieve thorough cleaning.
5. Chemical-free dry cleaning: No corrosive chemicals required and no wastewater generated, simplifying on-site environmental compliance.
6. Fast on-site operation: Quick connection and setup. Single-pass cleaning drastically cuts down working time compared with circulation flushing.
7. Pre-commissioning quality assurance: Removes welding slag, cutting chips and residual oil, helping pipelines pass pressure testing and cleanliness inspection.
8. Modular interchangeable nozzles: Multiple nozzle options to match different pipe diameters and connection types.

Short Version (For Alibaba International / Product Listing Card)

APS TUBE PNEUMATIC CLEANING AM-1 100

APS TUBE PNEUMATIC CLEANING AM-1 100 is a heavy-duty pneumatic pipe cleaning system for rubber hoses, aluminum, copper, stainless steel, iron and plastic tubes, rigid and flexible. Applicable ID: 63mm–100mm, larger sizes available on request.

Applications: Construction machinery, lifting equipment, HVAC heat exchangers, aerospace hydraulics, coal mine hydraulic supports, marine fuel piping, food transfer pipelines, defense & military hydraulic and fuel systems.

Working Principle: Dry physical cleaning driven by compressed air. Oversized foam projectiles move at high speed and scrub pipe inner walls. It passes through 90° elbows, T-pieces, U-bends and serpentine pipes, removing trapped water, sludge, weld debris and oil residues.

Highlights: Specially engineered for 63–100mm medium bore pipes, stable pneumatic power, chemical-free dry cleaning, non-destructive to pipe walls, rapid setup, modular nozzles, perfect for pipeline pre-commissioning cleaning.
